Casting Industry Straight Pneumatic Linear Vibrators FAL Series 150 ℃ Max Temperature
Feature
Big power with lower noise .
Standard frequency is form 10 to 60 times per minute .
Excitation force is from 12 N to 2740 N .
The frequency and vibration amplitude can be adjusted via regulating the working pressure .
The normal maximum working pressure is 150 degrees centigrade .
( We can also make special type , such as 200 degrees centigrade ) .
The pneumatic hammer can be used for severe environment .
Appplication
Hopper feed , Casting industry , Pipelining , Compaction , Screening , Conveyer , Etc
Structure
Aluminum shell with special high grade grease , long lifetime , is suitable for different application situation .
Technical Parameters
| Type | Frequency × 1000 | Vibration power ( N ) | Air consumption ( / min ) | A | C | D | E | F |
| Lenght | SW | Thread | Inlet | Outlet |
| 2 bars | 6bars | 2 bars | 6bars | 2 bars | 6bars | mm | mm |
| FAL – 18 | 1 . 42 | 2 . 25 | 60 | 205 | 20 | 60 | 117 | 50 | M - 10 | 1 / 8 “ | 1 / 8 “ |
| FAL – 25 | 1 . 13 | 2 . 02 | 120 | 530 | 40 | 155 | 139 | 65 | M - 16 | 1 / 4 “ | 1 / 4 “ |
| FAL – 35 | 1 . 24 | 2 . 01 | 205 | 655 | 75 | 350 | 140 |
| M - 16 | 1 / 4 “ | 1 / 4 “ |
Why choose us
1: Large stock for fast shipping .
2: High quality with competitive price .
3: Sample order & small quantity order is acceptable .
4: Reliable quality assured and active after-sell service
5: One year quality guarantee
FAQ
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: What ' s your delivery date ?
A: It depends on the number of orders . Delivery date is 7 - 30 days .if small order,pls buy from our aliexpress shop,
If you need emergency products , we can speed up the production of the first arrangement .
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: Do your company have specialized technical personnel ?
A: Design as your requirements,and have QC for make 100% inspection
